Design Kit – 5.8GHz Wideband FM Receiver Module
Doc No :
7. Absolute maximum ratings:
RF/ DC Parameters Min. Typ. Max. Unit
Storage Temperature Range
-25 - 85 °C
Supply voltage
4.5 - 5.5 V
The maximum rating must not be exceeded at any time. Do not operate the device under conditions outside
the above.
8. DC/AC Electrical characteristic:
(VCC=DC +5V, 25
°C)
RF/ DC Parameters Min. Typ. Max. Unit
Supply voltage
4.95 5 5.05 V
Supply current
210 mA
RF Input Level
-85 -10 dBm
Operating temperature
-10
-
60 °C
Operation Frequency Range
5725 5875 MHz
Channel Selection
PLL Synthesizer, 7CH (See Tabl1)
Channel Frequency
CH1： 5740 MHz, CH2： 5760 MHz
CH3： 5780 MHz, CH4： 5800 MHz
CH5： 5820 MHz, CH6： 5840 MHz
CH7： 5820 MHz.
Video-Audio Modulation/Demodulation Type
FM-FM
Video
Output Signal Level
1V
P-P
, typ. (+/-0.2Volt)
Frequency Response
+/-5 dB, max. 50Hz~5.5MHz
S/N Ratio (100KHz, 1V
P-P
Sine Wave)
40dB, min.
Audio
Output Frequency Range
50Hz ~ 20KHz
Output Signal Level (Modulation Signal :
1kHz Sine Wave)
2Vp-p
