Design Kit – 5.8GHz Wideband FM Receiver Module
Doc No :
1. Descriptions:
Airwave 5.8GHz Audio/Video wireless RF module contains one Transmitter and one Receiver. Using of
the most popular 5.8GHz ISM band and being designed with high reliability, Airwave RF module is
compliance with the criteria of FCC and R&TTE which can transmit/receive a wide band audio & video
signals up to 300 feet in open area. AWM660 RX module uses down conversion concept to convert the
5.8GHz RF Signal to 480 MHz IF signal, and then obtain base band via PLL FM demodulation IC by
Airwave AWI5822.
2. Feature:
 Worldwide 5.8GHz ISM band (5725 MHz～5875 MHz).
 Conform to R&TTE & FCC stipulation.
 Compatible with both NTSC and PAL video formats.
 Compact size and low power consumption.
 Highly efficient FM-FM modulation/demodulation scheme.
 Integrating Audio/Video input and output into one module base band PCB.
 Provide with 7 selectable channels.
 Received signal strength indicator (RSSI).
3. Application:
 AV Sender
 Baby Monitor
 Surveillance
 Wireless Camera
