Page 1 of 10 Rev

AIRWAVE TECHNOLOGIES INC.

4F, No.9 Industry E. 9

RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. TEL : 886-3-5778099 Fax 886-3-5778199

www.airwave.com.tw

Date : 2008/12/3

Design Kit – 5.8GHz Wideband FM Receiver Module

Doc No :

Company

FOR

ATTN

保密宣告

(Classified Info.)

本文列為機密文件，受雙方 NDA(Non-Disclose Agreement)所規範。

基此，請妥善保管文件，不可外洩給與合約無關之第三者造成雙方之損失。

The information contained herein is the exclusive property of Airwave Technologies

Inc.and shall not be distributed, reproduced, or disclosed in whole or in part without

prior written permission of Airwave Technologies Inc.

承認

承認品保工程

Dr. T.H. Chen Ben Huang Sandy Chen Shih Chuan Lin

Approve Approve QA E/E

AWM660 RX

5.8 GHz Wideband FM Receiver

Summary of content (10 pages)

PAGE 1
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 1 of 10 Rev Date : 2008/12/3 0 Company FOR ATTN 保密宣告 (Classified Info.) 本文列為機密文件，受雙方 NDA(Non-Disclose Agreement)所規範。基此，請妥善保管文件，不可外洩給與合約無關之第三者造成雙方之損失。 The information contained herein is the exclusive property of Airwave Technologies Inc.and shall not be distributed, reproduced, or disclosed in whole or in part without prior written permission of Airwave Technologies Inc. AWM660 RX 5.8 GHz Wideband FM Receiver 承認承認 Dr. T.H.
PAGE 2
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 2 of 10 Rev Date : 2008/12/3 0 Revision History Version Item 0.1 Initial version. Change Reason Date 03/31/2008 AIRWAVE TECHNOLOGIES INC. th 4F, No.9 Industry E. 9 RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. TEL : 886-3-5778099 Fax 886-3-5778199 Copyright © 2008 by Airwave Technologies Inc. All Specification are subject to change without notice. www.airwave.com.
PAGE 3
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 3 of 10 Rev Date : 2008/12/3 0 Contents 1. Descriptions 4 2. Feature 4 3. Application 4 4. Function block 5 5. Pin define 5 6. Pin descriptions 6 7. Absolute maximum ratings 6 8. DC/AC Electrical characteristic 7 9. Reference circuit 8 10. Dimension 9 AIRWAVE TECHNOLOGIES INC. th 4F, No.9 Industry E. 9 RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C.
PAGE 4
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 4 of 10 Rev Date : 2008/12/3 0 1. Descriptions: Airwave 5.8GHz Audio/Video wireless RF module contains one Transmitter and one Receiver. Using of the most popular 5.8GHz ISM band and being designed with high reliability, Airwave RF module is compliance with the criteria of FCC and R&TTE which can transmit/receive a wide band audio & video signals up to 300 feet in open area. AWM660 RX module uses down conversion concept to convert the 5.
PAGE 5
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 5 of 10 Rev Date : 2008/12/3 0 4. Function block: 5.725 GHz～5.875 GHz Zo = 50 ohm LNA Mixer LPF SAW IF Amp PLL Filter Zo=50 ohm RSSI FM Video Demod. CH1:5740 MHz, Lo=5260 MHz CH2:5760 MHz, Lo=5280 MHz Audio/L VCO CH3:5780 MHz, Lo=5300 MHz Audio/R CH4:5800 MHz, Lo=5320 MHz CH5:5820 MHz, Lo=5340 MHz CH6:5840 MHz, Lo=5360 MHz PLL Digital Control CKT CH7:5860 MHz, Lo=5380 MHz Note: Lo=RF-IF CH1 CH2 CH3 Channel Select 5.
PAGE 6
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 6 of 11 Rev Date : 2008/12/3 0 6. PIN descriptions: PIN 01 02 03 04 05 06 NAME VCC BYPASS GND Audio_R Audio_L Video Descriptions DC +5V power supply in). Bypass capacitor. Ground. Right sound signal output. Left sound signal output. Video signal output. 07 B2 Channel select. 08 B1 Channel select. 09 B0 Channel select. 10 GND Ground.
PAGE 7
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 7 of 11 Rev Date : 2008/12/3 0 7. Absolute maximum ratings: RF/ DC Parameters Min. Typ. Max. Unit -25 85 °C Storage Temperature Range 4.5 5.5 V Supply voltage The maximum rating must not be exceeded at any time. Do not operate the device under conditions outside the above. 8.
PAGE 8
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 8 of 11 Rev Date : 2008/12/3 0 9. Test circuit: AIRWAVE TECHNOLOGIES INC. th 4F, No.9 Industry E. 9 RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. TEL : 886-3-5778099 Fax 886-3-5778199 Copyright © 2008 by Airwave Technologies Inc. All Specification are subject to change without notice. www.airwave.com.
PAGE 9
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 9 of 11 Rev Date : 2008/12/3 0 10. Dimension: (1) with Pins AIRWAVE TECHNOLOGIES INC. th 4F, No.9 Industry E. 9 RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. TEL : 886-3-5778099 Fax 886-3-5778199 Copyright © 2008 by Airwave Technologies Inc. All Specification are subject to change without notice. www.airwave.com.
PAGE 10
Design Kit – 5.8GHz Wideband FM Receiver Module Doc No : Page 10 of 10 Date : 2008/12/3 Rev 0 (2) without Pins AIRWAVE TECHNOLOGIES INC. th 4F, No.9 Industry E. 9 RD., Science-Based Industrial Park, Hsinchu, Taiwan, R.O.C. TEL : 886-3-5778099 Fax 886-3-5778199 Copyright © 2008 by Airwave Technologies Inc. All Specification are subject to change without notice. www.airwave.com.
