Installation Guide
Table Of Contents
- Purpose & Applicability of This Guide
- Special Considerations and Safety Warnings
- Table of Contents
- 1. Introducing Intelligent Backhaul Radio (“IBR”)
- 2. Getting Started
- 3. Communicating with IBR
- 4. Preconfiguring IBRs
- 4.1.1 Web Graphical User Interface (GUI) – User names and passwords for the GUI are managed independently from CLI user names and passwords. For additional information, see the GUI section of the CLI Guide.
- 5. Installing IBR
- 5.3.1 Mounting Location - Choosing the best possible mounting location for IBR is important for safety, security, and link performance.
- 5.3.2 Fastback Networks’ Articulating Bracket - Fastback Networks offers an articulating mount that can be mounted on walls or masts and adjusted up to + 45 degrees in elevation and azimuth in 15 degree increments. The figure below shows the mountin...
- 6. Features & Functionality
- 7. Field Test Procedure
- Federal Communications Commission (FCC) Compliance Statement
IBR Installation Guide
Page 3 of 21 Doc # 770-00033.0
Jan. 22, 2016
Special Considerations and Safety Warnings
Prior to installing and operating this equipment, read all instructions and warning notices marked
on the equipment or in accompanying documentation.
Do not attempt to apply power to equipment that shows signs of damage, tampering, or
mishandling.
Do not open the equipment or attempt to repair or modify it. Doing so will void the warranty and
might create a safety hazard and/or cause the equipment to be out of compliance with regulations.
This equipment should be installed, operated, and serviced only by qualified personnel and in a
location that is accessible only by authorized service personnel.
Installation and operation of this equipment should be in compliance with applicable national and
local codes.
Ensure that this equipment is grounded at all times in accordance with local codes.
