8 Omega HD Manual, Fast Forward Video
VIDEO Ch 1 and VIDEO Ch 2
IN = SD/HD-SDI input BNC connectors.
OUT = SD/HD-SDI output BNC connectors.
RS:422 Ch 1 and RS:422 Ch 2 = Machine Control (DB9 CONNECTOR) - This connector is for controlling the deck or
the RS-422 with a controller it is recommended to lock the front panel (see page 11 Settings – Front Panel).
TIME CODE 1 and TIME CODE 2
IN = Input BNC connectors for longitudinal time code.
OUT = Output BNC connectors for longitudinal time code.
REFERENCE INPUT
170 for NTSC. Composite video or black burst are acceptable. DO NOT connect non-standard signals to the Omega
HD Deck, or the picture WILL distort.
Rear Panel Connections
Please NOTE:
n -
Channel 1 is RECORD only
Channel 2 is PLAYBACK only
