Dimensions Guide

Airflow / Energy Efficiency Info (120V)
Fan Speed Max RPM CFM CFM / Watts Amps Watts
High 193 5399 90 0.50 60
Med 133 3854 125 0.36 31
Low 80 2291 186 0.23 12
INSTALLATION REQUIREMENTS:
Fan must be attached to a securely anchored electrical junction
box capable of withstanding a load of at least 35 lbs.
ELECTRICAL REQUIREMENTS:
Requires a grounded electrical supply line of 120 volts AC, 60 Hz,
15 amp circuit.
MOTOR SPECS:
BLADES:
A set of three 21˝ reversible plywood blades is included.
LOCATION USE:
Fan is rated for dry location only.
LIGHTING OPTIONS:
One 100-watt halogen minican bulb included.
5.83˝ dia
Blade Sweep = 52˝ dia
A
B
Net Hanging Weight: 21.08 lbs
A B
Fan w/4.5˝ downrod 15.12˝ 11.55 ˝
Fan w/12˝ downrod 22.62˝ 19.05˝
Fan w/18˝ downrod 28.62˝ 25.05˝
Fan w/24˝ downrod 34.62˝ 31.05˝
Fan w/36˝ downrod 46.62˝ 43.05˝
Fan w/48˝ downrod 58.62˝ 55.05˝
Fan w/60˝ downrod 70.62˝ 67.05˝
Fan w/72˝ downrod 82.62˝ 79.05˝
CONTROL OPTIONS:
14° Blade Pitch
Available Finishes
Fan / Housing Assembly Blades
BN Brushed Nickel
Brushed Nickel Blade with
Opal Frosted Glass
AZ Aged Bronze
Cherry/Dark Walnut Blade
with Opal Frosted Glass
LP8081**
52˝ Ceiling Fan
COOP
™
Light Bulb Information (120V)
Bulb Type Watts Lumens Amount Color Temp CRI
100 1 1600 2750 99%minican
QTY
172 x 17 AC motor is designed for optimal performance with
this fan.
DOWNROD OPTIONS:
Fan comes with a 1˝ Dia. x 4.5˝ downrod (DRT1-45). Optional downrods are available in 12˝, 18˝, 24˝, 36˝, 48˝, 60˝ and
72˝. For installations requiring a longer downrod, a downrod coupler is available. Fan can be mounted on a sloped ceiling
up to 19°. Optional sloped ceiling kits (SCK1-52) are available for up to 42°. Call technical support for more information.
CW60WH-8081 wall control is included. This wall control has 3
fan speeds switch and light dimming switch. The reverse switch
is located on the top housing. Optional CW1SW, CW2
and CWRL4 wall conrtols available—sold separately.
Optional BTCR9, C4, CRL8TS and CRL4WH remote controls
with receiver unit and BTR9 receiver unit are available—sold
separately. Instructions are provided with each control.
Energy Guide FTC
Power
(Wave)
Total Air Delivery
(CFMave)
Estimated Yearly
Energy Cost ($)
Ceiling Fan
Efficiency
(CFM/W)
38 3585 11 95
