User Manual

• 3 Ovens:
LH – Programmable, multifunctional oven
RHB – Fan oven
RHT – Slow cook oven (80 – 140°)
• Telescopic runners - 2 shelves both ovens
• Rapid Response™
• Separate deluxe glide-out™ grill with 4-way trivet (dual-circuit)
• Seamless hob with three spill areas and five burners, including a
multi-ring burner, semi-gloss cast-iron pan supports, a wok cradle
and a multizone with two ceramic zones and a flat, aluminium
griddle
• Door-width handles / towel rails
SPECIFICATIONS – DUAL FUEL MODEL
IVORY
Trim: Satin Chrome
BLACK STAINLESS STEEL SLATE
GAS HOB / MULTIZONE
110cm
KEY FEATURES
HOB OPTIONS
NEXUS SE | Dual Fuel
NEXUS SE 110
HOB FUEL TYPE GAS (DF)
PRODUCT CODE NEXSE110DF
WIDTH ( mm) 1092
HEIGHT TO HOTPLATE ( mm) MIN/MAX 905 / 930
DEPTH EXCLUDING/INCLUDING HANDS ( mm) 608 / 648
WEIGHT (KG – UNPACKED) 147
HOB RATINGS
1 X 3.0 - 12.3MJ
1 X 3.8 - 15.2MJ«
2 X 1.55 - 6.2MJ
1 x 0.82 - 3.7MJ
TOTAL MJ RATING 43.60
ELECTRICAL RATING MULITZONE HOB 230V (kW) 2.20 (2 X 1.10)
RATED CONNECTED LOAD (AMPS) 52.00
RATED CONNECTED LOAD (kW) @230V 11.8
THREE-PHASE CONNECTION (AMPS) 3 X 18
MAXIMUM ELECTRICAL LOAD ( kW @ 230V)) 11.80
ELECTRICAL CONNECTION (AMPS)# 40#
GRILL POWER RATING ( kW) 2.3
SEPARATE GRILL GLIDE-OUT™ (TELESCOPIC)
OVEN TEMPERATURE °C MAX 240 °C
DIMENSIONS – LH OVEN (W xHxD) 466 X 434 X 359
CAPACITY – LH OVEN (LITRES) 79
DIMENSIONS – RH OVEN (W xHxD) 466 X 434 X 359
CAPACITY – RH OVEN (LITRES) 79
OVEN SHELVES (+1 = PLATE RACK) L: 2 FLAT / R: 2 FLAT
PAN SUPPORT MATERIAL CAST IRON
TIMER TYPE
3 BUTTON 24 HOUR/
WHITE DISPLAY
OVEN LIGHT BOTH OVENS
OVEN LINERS: CATALYTIC (C) / ENAMEL (E) BOTH OVENS: C
Oven dimensions are for information only; they should not be used to define
oven cookware dimensions.
(Single-handed
ignition)
Gas (DF)
#Using assessed maximum demand. Not all zones can be used at once. Consult with a licensed electrician.
MJ - MEGAJOULES - GAS
«
MULTI RING BURNER
