Manual

Section 2: Installation
Pillar and Beam Assembly
1. Thread the two (2) Pillar Support Rods (#1) into the tapped holes provided in the base.
• The end with the longer thread should fit into the platform (about 1⁄2 i n c h ).
2. Place the Pillar (#2) down over the support
rods with the pillar cut-outs facing the right and
left of the platform.
3. Insert the Steelyard Rod (#35) down through
the pillar.
• The bent hook on top; the loose S w i v e l
Hook on the bottom.
• The hook opening should be toward the
platform when properly placed.
• DO NOT remove the washers from the
Steelyard R od .
4. Hook the Steelyard Rod (#35) to the Long
Lever Tip Pivot (
#34).
• Temporarily, hook the upper end of the
Steelyard Rod on the pillar
cut-out.
Hook the Steelyard Rod to the
Long Lever Tip Pivot.
03/13 14 50699 Rev. 4
