Installation / Warranty Starck 10133XX1 Phoenix 17104XX1 Phoenix 17105XX1 Phoenix 17114XX1 Phoenix 17115XX1 Carlton 17135XX1 Carlton 17235XX1 Steel 35033801 Allegroh 36135XX1 Terrano 37135XX1 Terrano 37136XX1
Starck 10133XX1 Phoenix 17104XX1 Phoenix 17105XX1 Phoenix 17114XX1 2
Phoenix 17115XX1 Carlton 17135XX1 Carlton 17235XX1 Steel 35033801 3
Allegroh 36135XX1 Terrano 37135XX1 Technical data Hole size in deck Spout: min.1 1/4" max.1 5/8" Hole size in deck Valve: min.1 1/8" max. 1 1/4" Operating pressure: max. 147 psi Recommended operating press.:14.7 - 72.5 psi Test pressure: 232 psi Hot water temperature: max. 176° F Recommended hot water temp.
1 6 9 12 5 4 4c 4b 4a 11 10 2 13 8 2 3 7 3 7 18 14 21 16 19 15 11 20 17 2 2 22 3 3 7 5
Spare parts 24 27 1 2 3 4 26 25 11 2 7 3 17 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 Handle Stop unit for cold water Stop unit for warm water Aerator 4a Aerator casing 4b Sieve 4c Gasket Lift rod Spout cpl. Tube Fixation cpl. Handle for cold water Handle for warm water Aerator Lift rod Fixation cpl. Handle for cold water Handle for warm water Lift rod Fixation cpl. Handle for cold water Handle for warm water Aerator diverter knob Fixation cpl.
Spare parts 2 3 4 2 1 2 3 4 5 6 7 8 9 Aerator cpl. Handle cold / hot water Color-ring cold / hot water Escutcheon Tube Stop unit for cold water Fixation cpl. Lift rod Stop unit for warm water 96683800 35293800 97127000 97128800 94071000 96765000 96016000 96657800 96766000 1 3 5 6 7 9 Assembly 1. Flush pipe lines thoroughly. 2. Mount spout and valves onto lavatory. The hot water supply (red point on valve) should be connected to the LHS and the cold on the RHS. 3.
Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty. Cleaning Materials for Faucets and Showers • • • • To remove lime scale, use only products made specifically for that purpose.
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. („Hansgrohe“). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original consumer purchaser only. WHAT IS COVERED BY THE WARRANTY This warranty covers only your Hansgrohe manufactured product.
EXCLUSIONS AND LIMITATIONS REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE FOR IT ANY OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
05/2005 9.09450.07 12 Hansgrohe Inc. 1490 Bluegrass Lakes Parkway Alpharetta GA 30004 770 360 9880 website: www.hansgrohe-USA.
