Para instalación fácil de su llave Delta

usted necesitará:

LEER TODAS



LEER TODOS



-





For easy installation of your Delta

faucet you will need:

READ ALL



READ ALL







Pour installer votre robinet Delta

facilement, vous devez:

LIRE TOUTES-



LIRE TOUS









TWO HANDLE GARDEN ROMAN TUB TRIM

DE DOS MANIJAS PARA LA BAÑERA ROMANA

ESTILO JARDÍN

ROBINET DEUX MANETTES POUR BAIGNOIRE

ROMAINE DE JARDIN





Write purchased model number here.

Escriba aquí el número del modelo comprado.

Inscrivez le numéro de modèle ici.

You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:

























SILICONE

   



62091

Summary of content (4 pages)

PAGE 1
62091 TWO HANDLE GARDEN ROMAN TUB TRIM DE DOS MANIJAS PARA LA BAÑERA ROMANA ESTILO JARDÍN UP ® ROBINET DEUX MANETTES POUR BAIGNOIRE ROMAINE DE JARDIN C ® ASME A112.18.1 / CSA B125.1 Models/Modelos/Modèles T5722 Series/Series/Seria Write purchased model number here. Escriba aquí el número del modelo comprado. Inscrivez le numéro de modèle ici. You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin: SI lIC ON E TEF lON 1/8" (3.17mm) 3/32" (2.
PAGE 2
1 A. C. 1 2 4 3 3/32" (2.38 mm) 3/32 po 4 2 B. 1 4 5 NE ICO SIl 2 1 3 NOTE: The deck and valve rough-in must be finished before installing the trim kit. A. Unscrew the test cap (1) and discard. Screw bases (2) with gaskets (3) C. Install handles. If your model has plastic stems (1), be sure to install the retention screws (2) into the stems prior to installing the over end valves (4). Note: For tile applications that use the RP18235 handles.
PAGE 3
2 1 1 2 1 3 2 3 1 Maintenance If faucet leaks from spout outlet–Shut off water supplies – Turn faucet handles (1) all the way on. Turn on hot and cold water supplies and flush water lines for one minute. Important: This flushes away any debris that could cause damage to internal parts. Replace Seats and Springs (1).* If leak persists–Shut off water supplies–Replace Stem Unit Assembly (2).
PAGE 4
Warning: CLEANING AND CARE Scrubbing Bubbles ® Bathroom Cleaner and Lysol ® Basin Tub and Tile Cleaner must not be used on the clear knob handles and levers. Use of these cleaners can result in cracked or severely damaged handles. If overspray gets onto the handles, immediately wipe them dry with a soft cotton cloth. Care should be given to the cleaning of this product. Although its finish is extremely durable, it can be damaged by harsh abrasives or polish.
