User guide

4
SINGLE HANDLE KITCHEN FAUCET
403
PARTS LISTING
No Name Kit / Part #
1 Spout Seal kit A66D180
2O-Ring (Φ1-3/16" ID * Φ1-3/8" OD) A072090
3O-Ring (Φ7/8" ID * Φ1-1/8" OD) A004051
4 Ceramic Disc Cartridge A507348N
5 Locking Nut A104207
6 Trim Cap A103016XX
7 Metal Handle Assembly A662630XX
8 Screw (M5 * 5mm L) A008003
9O-Ring (Φ5/16" ID * Φ7/16" ID) A004001N
10 Supply Pipe- Cold A051404N
11 Supply Pipe- Hot A051406N
12 Back Flow Prevention Device A603661N
13 Coupling Nut A009016
14 O-Ring (Φ1-5/8" ID * Φ1-13/16" OD) A072032
15 Mounting Hardware A66D098ZN
16 Lock Nut A054062
17 Shank Adaptor Assembly A66D099N
18 O-Ring (Φ5/16" ID * Φ1/2" OD) A004031N
19 Check Valve A519204N
20 Hose Adaptor Assembly A663880
21 Hose Guide A126690KP
22 Seal A058007
23 Hand Spray w/ Check Valve A500579NXX
24 Aerator A500859NXX
25 Hex Wrench (H2.5 * 19 mm L * 53 mm L) A031000
26 Weight A504713
27 Spray Hose A512101NXX
28 Base Trim Ring A667181XX
XX designates finish matched parts
