Exploded Parts

INCA HC 2019 SSV

body components

Model Number INHC29SSV INHC35SSV

Key Description 29 Stainless 35 Stainless Qty Req.

1 Grease Filters 133.0189.437 133.0189.437 3

10 Hinge Clip Kit (2 in kit) 133.0078.993 133.0078.993 1

11 Rubber Stopper 133.0017.608 133.0017.608 1

21 Vent Grate 133.0016.964 133.0016.964 1

22 Damper 133.0055.994 133.0055.994 1

33 LED Bulb 133.0486.867 133.0486.867 2

36 Lamp Holder 133.0380.507 133.0380.507 1

39 Lamp holder Support 133.0198.226 133.0198.226 2

69 Bulb Clip 133.0200.447 133.0200.447 1

Rev. 04/19

X 12

PAGE 1
INCA HC 2019 SSV body components X 12 50 10 Key 1 10 11 21 22 33 36 39 69 22 Model Number INHC29SSV INHC35SSV Description 29 Stainless 35 Stainless Qty Req. Grease Filters Hinge Clip Kit (2 in kit) Rubber Stopper Vent Grate Damper LED Bulb Lamp Holder Lamp holder Support Bulb Clip 133.0189.437 133.0078.993 133.0017.608 133.0016.964 133.0055.994 133.0486.867 133.0380.507 133.0198.226 133.0200.447 133.0189.437 133.0078.993 133.0017.608 133.0016.964 133.0055.994 133.0486.867 133.0380.507 133.
PAGE 2
INCA HC 2019 SSV switch / motor components Model Number INHC29SSV INHC35SSV Key Description 29 Stainless 29 Stainless Qty Req. 101 190 302 305 310 312 399 Control Button Kit Control Board Kit Impeller Kit Rubber Motor Mount Power Cord 25 MF Capacitor Motor Kit SSV 133.0380.478 133.0524.811 133.0052.799 133.0051.604 133.0381.468 133.0060.648 133.0554.637 133.0380.478 133.0524.811 133.0052.799 133.0051.604 133.0381.468 133.0060.648 133.0554.637 1 1 1 1 1 1 1 Rev.
