Note: Always be careful when handling electricity wiring. If you’re not comfortable
to do it yourself, do consult a qualified electrician.
Step 3: Select the mounting plate.
Install directly by the mounting plate, or use one of the inclined mounting plates as a
supplementarymountingbracketifyouwishtoseemoreonaspecicside.
Door
Doorbell
Without
Inclined Mounting Plate
Door
Doorbell
15°
With
Inclined Mounting Plate
Step 3: Install the mounting plate.
If the wall is smooth:
- Stick the plate foam on the mounting plate and then paste them to the wall.
If the wall is uneven,
- Place the drill template onto the surface you have chosen to mount the doorbell.
(Optional) Drill four screw holes and insert anchors. There is no need to use anchor
if you were installing on wooden doorframe.
Anchor
It is recommended to use a drill with diameter of 6mm.
