PLATFORMS/LANDINGS
 Made with aircraft grade aluminum.
 Slip resistant Gecko Grip® walking surface.
 5.5” minimum landing/platform height without support legs.
 42” (nominal) frame (top rail) height.
 4” (maximum) guard picket spacing.
 22” (nominal) frame midrail height (Two-Line Rails).
 Designed for a uniform live load of 100 lbs. per square foot (psf) min. and a concentrated vertical load of 300 lbs.
Platform size
5’ x 5’
(5’ rails)
5’ x 6’
(5’ rails)
5’ x 6’
(5’ & 6’ rails)
5’ x 6’’
(6’ rails)
6’ x 6’
(6’ rails)
5’ x 7’
(5’ rails)
5’ x 7’
(5’ & 7’ rails)
5’ x 7’
(7’ rails)
1’ x 4.5’
Extender
(1’ rails)
1’ x 5’ Extender
(1’ rails)
Platform Outside
Dimensions
65.5” x 65.5” 65.5” x 77.5” 65.5” x 77.5” 65.5” x 77.5” 77.5” x 77.5” 65.5” x 89.5” 65.5” x 89.5” 65.5” x 89.5” 59.5” x 17.5” 65.5” x 17.5”
Platform Only
w/o Rails Weight
(lbs.)
81.6 94.3 94.3 94.3 107.8 107.0 107.0 107.0 28.6 30.8
Two-Line Rail
Pair Weight
(lbs.)
41.8 41.8 43.6 45.4 45.4 41.8 45.8 49.8 27.6 27.6
Guard Pair
Weight (lbs.)
47.0 47.0 49.6 52.2 52.2 47.0 52.6 58.2 28.2 28.2
Width to Outside
of Support Feet
65.68” x 65.68” 65.68” x 77.68” 65.68” x 77.68” 65.68” x 77.68” 77.68” x 77.68” 65.68” x 89.68” 65.68” x 89.68” 65.68” x 89.68” 59.59” x 17.59” 65.59” x 17.59”
TABLE 4
LEGS
 Made with aircraft grade aluminum.
 6061-T6 or 6005-T5 aluminum alloy construction.
 Each leg terminates into a 7.375” square polymer foot.
 1.5” square; lengths vary.
 Weights vary by length (0.67 Lb. /inch).
 Legs install perpendicular to the ground plane; vertical loads transmit axially through legs.
