Dimensions Guide

Page 4 of 9
DIMENSIONAL SPECIFICATIONS
 Unless otherwise specified, weights are expressed in pounds; lengths and widths in feet and/or inches.
 Weights and dimensions are approximate, contact manufacturer for more information.
RAMPS
 Made with aircraft grade aluminum.
 Slip resistant Gecko Grip® walking surface.
 4” side rail curb height.
 1.5” handrail diameter.
 36” (nominal) handrail height.
 25” (nominal) child handrail height.
 42” (nominal) frame (top rail) height.
 4” (maximum) guard picket spacing.
 21.5” (nominal) frame midrail height.
 Designed for a uniform live load of 100 lbs. per square foot (psf) min. and a concentrated vertical load of 300 lbs.
48” WIDE RAMPS
2’ Ramp
3’ Ramp
4’ Ramp
5’ Ramp
6’ Ramp
Starter Ramp
Ramp Weight (lbs.)
28.5
41.3
54.1
66.9
79.8
75.1
Useable Dimensions
2’ x 48”
3’ x 48”
4’ x 48”
5’ x 48”
6’ x 48”
6’ x 48”
Handrail Pair Weight (lbs.)
2.5
3.3
4.2
5.1
6
5.97
Handrail w/ Child Rail Pair Weight (lbs.)
5
6.6
8.4
10.2
12
N/A
Two-Line Rail Pair Weight (lbs.)
20.2
22.5
24.7
26.9
29.1
29
Guard Pair Weight (lbs.)
23.3
28.2
33.1
37
41.9
41.7
Outside Dimensions 54.81” Foot to Foot
60.46”
Post Support to
Post Support
TABLE 1
54” WIDE RAMPS
2’ Ramp
3’ Ramp
4’ Ramp
5’ Ramp
6’ Ramp
Starter Ramp
Ramp Weight (lbs.)
31.2
45.3
59.3
73.4
87.5
82.3
Useable Dimensions
2’ x 54”
3’ x 54”
4’ x 54”
5’ x 54”
6’ x 54”
6’ x 54”
Handrail Pair Weight (lbs.)
2.5
3.3
4.2
5.1
6
5.97
Handrail w/ Child Rail Pair Weight (lbs.)
5
6.6
8.4
10.2
12
N/A
Two-Line Rail Pair Weight (lbs.)
20.2
22.5
24.7
26.9
29.1
29
Guard Pair Weight (lbs.)
23.3
28.2
33.1
37
41.9
41.7
Outside Dimensions 60.81” Foot to Foot
66.46”
Post Support to
Post Support
TABLE 2
60” WIDE RAMPS
2’ Ramp
3’ Ramp
4’ Ramp
5’ Ramp
6’ Ramp
Starter Ramp
Ramp Weight (lbs.)
33.1
50.8
66.7
82.4
98.3
89.5
Useable Dimensions
2’ x 60”
3’ x 60”
4’ x 60”
5’ x 60”
6’ x 60”
6’ x 60”
Handrail Pair Weight (lbs.)
2.5
3.3
4.2
5.1
6
5.97
Handrail w/ Child Rail Pair Weight (lbs.)
5
6.6
8.4
10.2
12
N/A
Two-Line Rail Pair Weight (lbs.)
20.2
22.5
24.7
26.9
29.1
29
Guard Pair Weight (lbs.)
23.3
28.2
33.1
37
41.9
41.7
Outside Dimensions 60.81” Foot to Foot
66.46”
Post Support to
Post Support
TABLE 3
