Section 4: Advanced Setup Procedures VN-MATRIX User Guide
Page 64 I458GB issue 6
Video Setup Page
All advanced source setup is achieved via the Video Setup page. This is accessed by clicking the
Video Setup tab on the Configure (videoPort) page for the relevant VN-MATRIX encoder:
For most source types it is recommended
that you select the auto input mode,
allowing full auto-detection of the source.
To apply a fixed input mode, select the
required mode from the drop down list and
click Update or Save.
NOTE: Selecting a fixed input mode
disables the auto-detect function.
