Panels and
Cabling
This section discusses the MPA 152 rear panel features and cabling.
MPA 152 Rear Panel Features
The rear panel of the MPA 152 (shown in Figure 2 below) allows the user to connect power,
audio input, speakers, and remote control.
POWER
12V
0.6A MAX
OUTPUT
4/8
OHMS
CLASS 2 WIRING
DO NOT GROUND
OR SHORT
SPEAKER OUTPUTS!
INPUTS
L
R
L
R
REMOTE
VOL/MUTE
10V 50mA
L
MPA 152
R
1 2 3 654
Figure 2. MPA 152 Rear Panels Features
