Command ASCII Command
(host to unit)
Response
(unit to host)
Additional Description
Reset
Reset configurable
settings to factory
defaults
EZXXX} Zpx]
VolX!]
Resets all user defined configurable
settings to the factory defaults.
Maintains voltage and resistance
outputs and device name.
Reset all configurable
settings, device name,
outputs, and flash
memory to factory
defaults
EZQQQ} Zpq]
Vol000]
Resets all configurable settings, device
name, outputs, and flash memory to
factory defaults.
NOTE: This command does not
reset firmware to the
factory default.
Information Requests
Query firmware version
Q
X&]
Shows firmware version in format x.xx
Set
device name
E X* CN}
IPN•X*] The device name (X*) is a alphanumeric
string of up to 24 characters that allows
the user to uniquely identify the device.
The default name is MLA-VC10-PLUS.
Set
device name to
factory default
E•CN}
IPN•MLA-VC10-
PLUS]
View device name
ECN} X*]
Query model name
I
MLA
•VC10•
PLUS]
Shows the model name.
Request
part number
N
60-1090-01
]
Shows the part number.
