Control Resistance and Voltage for Common Amplifiers
The table below shows the control resistance and control voltage requirements for a selection of
common ampliers. The MLA VC10 Plus is compatible with a wide range of ampliers. The models
shown in this table are included as examples only. The MLA VC10 Plus is not limited to working
with only the amplifiers shown in this guide. The majority of amplifiers researched and tested by
Extron work with the MLA VC10 Plus straight from the box, using 10 kilohm resistance control.
ATTENTION: Extron has attempted to ensure that these specications are accurate. However,
they may change without notice. Using a control voltage that is too high will
damage the amplifier. Always verify the control voltage by checking the user
guide for the amplifier or measuring it yourself.
Wiring may use two terminals (A in the Wiring column) or three terminals (B in the Wiring column).
Manufacturer Model Control Resistance Control Voltage Wiring
Ashly PE Series 10 kilohm 5 VDC B
Pêma Series 10 kilohm 5 VDC B
NE Series 10 kilohm 5 VDC B
Atlas Sound AA120 10 kilohm A
AA120M 10 kilohm A
AA240 10 kilohm A
AA35 10 kilohm A
PA1001G 10 kilohm A
Australian
Monitor
Amis Series 500 kilohm A
MX Series 500 kilohm A
TX Series 500 kilohm A
Biamp MXA Series 5 or 50 kilohm 10 VDC B
IWA 250 5 or 50 kilohm 10 VDC B
301 5 or 50 kilohm 10 VDC B
601 5 or 50 kilohm 10 VDC B
801 5 or 50 kilohm 10 VDC B
