Reference Inforation, cont’d
Matrix 12800 Switchers • Reference Information
B-6
PRELIMINARY
Terination tool and connector Part nuber
CTU 300 universal crimp tool 100-241-02
BNC Male RG6 Crimp Connectors (qty. 100) 100-339-01
BNC Male MHR Cable Crimp Connectors (qty. 100) 100-335-01
CTU 100 universal compression tool (BNC, F, RCA) 100-181-01
BNC Male RG6 Compression Connectors - Nickel/50 (qty. 50) 100-188-01
BNC Male MHR Compression Connectors - Nickel/50 (qty. 50) 100-186-01
BNC Male RG59P Compression Connectors - Nickel/50 (qty. 50) 100-212-01
Terinated cable aeblie
S-video cable Part nuber
MHR-2 SVM-M, 6' to 100' (1.8 m to 30.4 m) 26-316-nn
MHR-2P SVM-M, Plenum, 6' to 100' (0.9 m to 30.4 m)) 26-522-nn
Copoite video ale-to-ale cable
RG6 BNC, 3' to 100' (0.9 m to 30.4 m) 26-383-nn
