User Guide

Reference
Information
This section discusses the specifications, part numbers, and accessories for the
FOXBOX SR HDMI. Topics that are covered, include:
• Part Numbers
• Mounting the Unit
Part Numbers
FOXBOX SR HDMI Part Numbers
The FOXBOX receiver is available in a singlemode (SM) and multimode (MM) model:
FOXBOX SR HDMI Part number
FOXBOX SR HDMI SM 60-1187-22
FOXBOX SR HDMI MM 60-1187-21
Included Parts
These items are included in each order for a FOXBOX SR HDMI receiver:
Included parts Part number
12V, 1A external power supply, with IEC power cord (qty. 1)*
SFP Module (SM or MM, depending on the model)
LockIt Lacing Bracket and tie-wrap (qty. 1) 21-235-01LF
Captive screw 5-pole connectors (qty. 2) 10-703-12
Captive screw 3-pole connector (qty. 1) 10-319-13LF
10' LC-LC duplex patch cable (SM or MM, depending on the model)
Rubber feet (qty. 4)
Extron Software Products DVD
(Signal Processing Product Control Program)
FOXBOX SR HDMI Setup Guide
* ZipClip 100 Mounting Kit available separately, see “Mounting Accessories,”on the next
page.
