Video output— receiver
Number/signal type ........................ 1 dual link DVI-D*
Connectors .................................... 1 DVI-I female
NOTE: *Dual link DVI is backwards compatible with all single link DVI/HDMI
signals.
Control/remote — external device (pass-through)
Serial control port input
Transmitter ................................ RS-232 via (1) 3.5 mm, 3 pole captive screw connector
Receiver ..................................... 1 set of proprietary signals on a female RJ-45 jack
Serial control port output
Transmitter ................................ 1 set of proprietary signals on a female RJ-45 jack
Receiver ..................................... RS-232 via a 3.5 mm, 3 pole captive screw connector
NOTE: Protocol is mirrored between the transmitter and the receiver.
Serial control pin configurations ..... Captive screw connectors: 1 = Tx, 2 = Rx, 3 = GND
General
Recommended cable type .............. CAT 5/5e/6 (shielded or unshielded) or Extron DTP26
External power supply.................... 100 VAC to 240 VAC, 50-60 Hz, 6 W max., external; to 12
VDC, 2 A, regulated
Power input requirements .............. 12 VDC, 0.4 A for both transmitter and receiver
NOTE: Each transmitter and receiver can be powered locally by an external
power supply. The receiver can be powered remotely by a power supply
connected to the transmitter on the other end of the CAT 5/5e/6 or
Extron DTP26 cable.
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%,
noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%,
noncondensing
Cooling ......................................... Convection, no vents
Mounting
Rack mount ............................... Yes, with optional 1U rack shelf
Furniture mount ........................ Yes, with optional through-desk mounting kit
Pole mount ................................ Yes, attachable to a projector pole mount using optional
mounting kit
Enclosure type ............................... Metal
Enclosure dimensions
DVI DL 201 TX ........................... 1.75" H x 8.75" W x 3.0" D (1U high, half rack wide)
4.4 cm H x 22.2 cm W x 7.6 cm D
(Depth excludes connectors.)
DVI DL 201 RX ........................... 1.0" H x 4.3" W x 3.0" D (quarter rack wide)
(2.5 cm H x 10.9 cm W x 7.6 cm D)
(Depth excludes connectors.)
Product weight .............................. Transmitter: 0.6 lbs (0.3 kg)
Receiver: 0.3 lbs (0.1 kg)
Transmitter and receiver: 0.9 lbs (0.4 kg)
Shipping weight ............................ 2 lbs (1 kg)
