This section describes the panel features and cabling of the DVI DL 201 Tx and
DVI DL 201 Rx:
z DVI DL 201 Tx Front Panel
z DVI DL 201 Tx Rear Panel
z DVI DL 201 Rx Front Panel
z DVI DL 201 Rx Rear Panel
DVI DL 201 Tx Front Panel
The illustration below shows the front panel features of the DVI DL 201 Tx.
DVI DL 201 Tx
DVI DUAL LINK TRANSMITTER
1
Figure 2. DVI DL 201 Tx Front Panel Features
a LED — An amber light indicates that the DVI DL 201 Tx is receiving power from a
power supply. A green light indicates that the transmitter is also receiving a video
signal.
