Installation Checklist
 Determine which source will be used for the EDID information and configure the DDC
switches appropriately (see pages 13 to 16). If necessary, use the EDID Minder to read and
store information from a display (
see pages 13 to 14).
 Prepare twisted pair cables (see “Terminating shielded cable”).
 Connect the transmitter to the receiver (see “Connections”)
 Connect the source device to the transmitter (see “DVI-D input”). Do not power on the
source device at this time.
 Connect the display device to the receiver (
see “DVI-D output”). If required, connect a local
monitor to the transmitter.
 If required, connect any RS-232 or IR control devices (see “Control pass-through”).
 Connect the power supply to the transmitter (see “Power input”).
CAUTION: Read all the Cautions in the “Power Input” section.
 Power on the display device.
 Power on and boot up the source device.
