DMS 1600, DMS 2000, DMS 3200, and DMS 3600 • Installation 6
Installation
This section describes the installation of the DMX matrix switchers, including:
• Setup and Installation Checklist
• Rear Panel Cabling and Features
• Front Panel Configuration Port
Setup and Installation Checklist
Get ready
c Familiarize yourself with the DMS matrix switcher.
c Obtain IP setting information for the matrix switcher from the local network administrator
(see Ethernet Connection on page 108).
Configure the matrix switcher
c Install the desired I/O boards (page 101).
Perform physical installation
c Create (page 83) and replace (page 106) button labels (optional).
c Install the switcher in a rack (page 100) (optional).
c Cable input and output devices to the I/O boards (page 9).
c Connect computers or control systems to any of the remote control ports (a serial
[RS-232/RS-422] port [page 11], a USB port [page 13], and a LAN port [page 11]) on
the switcher (optional).
c Connect power (page 13).
c Test the switcher by creating a tie (page 23).
Ancillary operations
c Install the Matrix Switchers Control Program (page 61).
