Operation, cont’d
MGP 464 • Operation
3-12
PRELIMINARY
Resolution and Refresh Rate submenu
While this submenu is displayed, rotate the horizontal Adjust (
[
) knob to select
one of the available resolutions, or rotate the vertical Adjust ({) knob to select one
of the available refresh rates. The resolutions and refresh rates are listed in the
following table.
Resolution
Refresh Rates
50 Hz 60 Hz 72 Hz 96 Hz 100 Hz 120 Hz
640 x 480 X X X X X X
800 x 600 X X X X X X
852 x 480 X X X X X
1024 x 768 X X X X
1024 x 852 X X X X
1024 x 1024 X X X
1280 x 768 X X
1280 x 1024 X X
1360 x 765 X X
1365 x 768 X X
1366 x 768 X X
1365 x 1024 X X
1400 x 1050 X X
1600 x 1200 X X
480p X
576p X
720p X X
1080i X X
1080p X X
DVI BCKGD* RATE Resolution and clock of the incoming background input
* When DVI BCKGD is selected as the output resolution/rate, the MGP uses
the incoming DVI background input resolution and clock as the output rate.
The sync type and polarity options are available for the RGB output while the
background timings are used. If available, the output of the MGP is locked to
the DVI background rate until you select a different resolution or disconnect
the DVI background input.
By default, the resolution provided in the Extended Display Identication
Data (EDID) is the last selected factory rate. To manually set the resolution
information provided in the EDID data, see the Set EDID information SIS
command on page 4-9.
Output Type submenu
Rotate either the horizontal Adjust (
[
) or the vertical Adjust ({) knob to select
the output signal type required by the display device. Available signal types are
RGBHV, RGBS, YUV bi-level and YUV tri-level. The default is RGBHV.
