Specification Sheet

08/02 - R1
Features:
• Super large 1.4" (36mm) LCD display
• Dual display of oxygen and temperature
• Measures dissolved oxygen from 0 to 20.0mg/L and 0 to 100.0% oxygen
plus temperature from 32 to 122°F (0 to 50°C)
•
Automatic Temperature Compensation
from 0 to 50°C via temperature probe sensor
built into polarographic type oxygen probe
• Fast 0.8 second sampling time
• Recall Min/Max/Average readings
• Data Hold
• Built-in RS-232 PC serial interface with
optional data acquisition software and datalogger
• Auto power off saves battery life
• Kitted complete with 0.8"(20mm) diameter probe on 44" (1.1m) cable,
5 membranes, rubber holster, 9V battery and hard vinyl carrying case
• Optional Windows
®
Data Acquisition Software and
serial cable enable user to display and capture readings
on a PC, and set time intervals and alarms
•
Optional battery operated Datalogger module
stores over 8000 readings for later transfer to a PC
ISO 9001 CERTIFIED
Heavy Duty Dissolved Oxygen Meter
Dual display of oxygen concentration and temperature plus RS-232 PC interface
3
Warranty
Year
Ordering Information:
407510 ......Heavy Duty Dissolved Oxygen Kit
407515 ......Heavy Duty Dissolved Oxygen Kit with 13' (4m) cable
Accessories:
780407 ......Replacement Membranes (5/pack)
780408 ......KCL Solution
156119 ....117 VAC Adaptor
156221 ....220 VAC Adaptor
Options:
407001 ......Data Acquisition Software and cable
380340 ....Battery operated Datalogger Module
Specifications: Dissolved Oxygen Oxygen Temperature
Range: 0 to 20.0 mg/L 0 to 100.0% 32 to 122°F
(0 to 50°C)
Accuracy: ±0.4 mg/L ±0.7% ±0.8°C/1.5°F
Probe Compensation
& Adjustment: Salt: 0 to 39% Altitude: 0 to 3900m Temp: 0 to 50°C
Dimensions/Weight: 7x2.9x1.3” (178x74x33mm) / 17oz (meter only)
Probe: 20mm(0.8”)D 125mm(4.9”)L
