CAD 2D (pdf)

XL-GR
Graphite Textured
Painted
FEATURES & BENEFITS
XLERATOR
®
HAND DRYER
MODELS: XL -
BW W GR C SB SI SP
OPTIONS: -1.1N (Noise Reduction Nozzle) -VOLTAGE (See Chart)
XL-BW
White Thermoset Resin (BMC)
XL-C
Chrome
Plated
XL-SB
Brushed Stainless
Steel
XL-W
White Epoxy
Painted
XL-SI
***
Custom Special
XL-SP
**
Custom Special
Paint
WEIGHT
DIMENSIONS
Width 11
3
/4" (298 mm) Height 12
11
/16" (322 mm) Depth 6
11
/16" (170 mm)
XL-BW : 15 lbs. (6.8 kgs.) XL-SB : 16 lbs. (7.26 kgs.) XL-W, GR, C, SI, SP : 17 lbs. (7.71 kgs.)
RoHS
Width 16
3
/8
" (416 mm) Height 26" (660 mm)
Depth 3
3
/8" (86 mm) Weight 11 lbs. (4.99 kgs.)
Anti-Microbial Wall Guards
XChanger Paper Towel Dispenser
Retrofit Kit
ADA-Compliant Recess Kit
%
%
%
ACCESSORIES
Part # 40502
Automatic Sensor Operated Surface Mounted
ACTIVATION MOUNTING
SUGGESTED MOUNTING HEIGHTS
Men 45" (114 cm) Women 43" (109 cm) Handicapped 37" (94 cm)
Note: Heights measured from floor to bottom of dryer.
-H (HEPA Filter)
OPTIONS
• HEPA Filtration System: Filters 99.97% of bacteria at 0.3 microns from the air stream.
• 1.1 Noise Reduction Nozzle: Lowers decibel level 9 dB by reducing air deflection noise
but increases dry time by approximately 3 seconds.
%
%
ELECTRICAL
110-120V
208-277V
230V
11.3-12.2A
5.6-6.2A
6.1A
1240-1450W
1160-1490W
1410W
4.3-4.5A
2.0-2.2A
2.2A
VOLTS AMPS WATTS NO HEAT AMPS NO HEAT WATTS
460-530W
425-500W
500W
HERTZ
50/60 Hz
50/60 Hz
50 Hz
TIME TO THROW IN THE TOWEL
®
EXCEL DRYER INC • 1.800.255.9235 • EXCELDRYER.COM
2016
AUGUST
16XLS0001
Excel Dryer is proud to lead the industry into a new age of transparency by initiating
and chairing the first global Product Category Rule (PCR) with UL Environment, the
first step in developing Environmental Product Declarations (EPDs). PCRs enable
specifiers and buyers to make an apples-to-apples comparison of a product's
environmental impact, and ultimately make more informed purchasing decisions.
ONLINE INFORMATION
Product Videos
Cost Savings & Carbon Footprint Calculator
Life Cycle Assessment Study
P
$
7
=
B
K
Specification Tools
AIA/GBCI CEU Courses
Case Studies
* Dry time and energy use testing performed by SGS International on standard XLERATOR Hand Dryer with 0.8"
nozzle to 0.25g or less of residual moisture, pursuant to the UL Environment Global Product Category Rules (PCR)
for Hand Dryers.
**
Special Paint powder-coated covers are available in many colors and textures.
***
Exclusive digital image technology allows for the addition of company, school or team logos with any color, design
or a 'green message'.
• 80% Less Energy Than Conventional
Hand Dryers
• 95% Cost Savings Vs. Paper Towels
• Made In USA Certified
®
• 5-Year Limited Warranty
• Building Green Approved and Helps
Qualify for several LEED
®
credits
• A Hygienic Hand Drying Solution
%
%
%
%
% %
DRY TIME: 8 SECONDS* ENERGY PER USE: 3.7 Wh*
