• For a network of two or more radios using Internal Sync, connect using the ExaltSync Collocation
kit.
• For a network of two or more radios using GPS Sync, connect using one GPS kit and the
ExaltSync Collocation kit, or connect using one GPS kit per link.
Radio A/B Configuration
Use the Exalt GUI to configure the radio terminals for Radio A and Radio B orientation. Since many
other parameters also need to be set, and the Exalt GUI is needed for these configurations, this is the
best way to completely configure the radio terminals.
Radios arrive from manufacture in default configuration, orientated as Radio B and configured as
shown in Table 1.
Table 1 Factory default settings
Parameter ExtendAir (TDD) Series Radio Settings
Frequency 5GHz models: 5788 MHz (5600 or 5785 MHz if the regulatory domain does not
allow 5788 MHz)
4.9GHz models: 4965 MHz
Transmit Power +4dBm
Link Distance <10 miles
Bandwidth 8 MHz (10 MHz for some regulatory domains)
Mode Mode 1
TDD Frame Size 2ms
Link Security Key 000000000000
Administration
Password
password
User Password password
IP Address 10.0.0.1
IP Mask 255.0.0.0
IP Gateway 0.0.0.0
Ethernet Interface Alarm Enabled, 100/Full
T1/E1 Enabling All Disabled
