- ExtendAir® (TDD) Series Digital Microwave Radios Installation and Management Guide
- Legal Notice
- Open-Source License Information
- Table of Contents
- Notes for Customers of the Cisco Configuration ExtendAir r5005
- About this Document
- Introduction
- Pre-installation Tasks
- Link Engineering and Site Planning
- Familiarization with the ExtendAir (TDD) Series Radios
- Initial Configuration and Back-to-Back Bench Test
- Time Division Duplex (TDD) Factors
- Link Orientation and Synchronization
- Radio Synchronization
- Offset Timing
- Virtual Local Area Network (VLAN)
- Simple Network Management Protocol (SNMP)
- System Installation and Initiation Process
- Installation
- Configuration and Management
- Telnet into the Command Line Interface (CLI)
- Telnet
- Exalt Graphical User Interface (GUI)
- Quick Start
- Navigating the GUI
- Radio Information Page
- Administration Settings Page
- NTP and Time Zones Configurations Page
- Simple Network Management Protocol (SNMP) Configuration
- File Management Pages
- File Transfer Page
- File Activation Page
- System Configuration Page
- Ethernet Interface Configuration Page
- T1/E1 Configuration Pages
- VLAN Configuration Page
- Ethernet Rate Limiting
- QoS Configuration Page
- Automatic Channel Selection (ACS) Page
- Syslog Configuration Page
- GPS Information Page
- Alarms Page
- Performance Page
- Event Log Page
- User Throughput Page
- Diagnostic Charts Page
- Spectrum Analyzer Page
- Ethernet Utilization Page
- Reboot Page
- Manual Page
- Specifications
- Interface Connections
- Antennas
- Troubleshooting
- Back-to-back Bench Testing
- General Compliance and Safety
- Dynamic Frequency Selection
- Safety Notices
- Regulatory Notices
- Regulatory Compliance
- EIRP Limits for the United States and Canada
- EIRP Limits for Australia
- EIRP Limits for the European Union and ITU Countries
- Declaration of Conformity to the R&TTE Directive 1999/5/EC
- Exalt Limited Hardware Warranty Software License and RMA Procedures Agreement
- Copyright Notices
- Index
Exalt Installation and Management Guide
ExtendAir (TDD) Series Digital Microwave Radios
2 203591-011
2013-02-22
The following ExtendAir (TTD) models are covered in this manual:
• r4005 and rc4005
– configured with 27Mbps aggregate Ethernet capacity (1PoE port plus two additional Ethernet
ports)
– with license key upgrades for 55 and 160Mbps aggregate capacity
• r4010 and rc4010
– configured with 27Mbps aggregate capacity and 4xT1/E1 (single PoE port)
– with license key upgrades for 55 and 160Mbps aggregate capacity
• r4900 and rc4900
– configured with 27Mbps aggregate Ethernet capacity (single PoE port)
– with license key upgrades for 55, 80, and 162Mbps aggregate capacity
• r4905 and rc4905
– configured with 27Mbps aggregate Ethernet capacity (1 PoE port plus 2 additional Ethernet
ports)
– with license key upgrades for 55, 80, and 162Mbps aggregate capacity
• r4910 and rc4910
– configured with 27Mbps aggregate capacity and 4xT1/E1 (single PoE port)
– with license key upgrades for 55, 80, and 162Mbps aggregate capacity
• r5000 and rc5000
– configured with 27Mbps aggregate Ethernet capacity (single PoE port)
– with license key upgrades for 55 and 162Mbps aggregate capacity
• r5005 and rc5005
– configured with 27Mbps aggregate Ethernet capacity (1 PoE port + 2 additional Ethernet
ports)
– with license key upgrades for 55 and 162Mbps aggregate capacity
• r5010 and rc5010
– configured with 27Mbps aggregate capacity and 4xT1/E1 (single PoE port)
– with license key upgrades for 55 and 162Mbps aggregate capacity
• r5015 and rc5015
– configured with 2Mbps aggregate Ethernet capacity and 2xT1/E1 (single PoE port)
– with license key upgrades for 27, 55, and 162Mbps aggregate capacity with license key
upgrade for 4xT1/E1
Note: All models offer license key upgrades for 128- or 256-bit AES encryption.
Note: The Cisco configuration r5005 is pre-configured to allow full capacity (162Mbps
aggregate) and 128-bit AES wireless encryption.
