Laird GD53-28 Grid Parabolic Dish 3 ft Single 28
Laird GD57-28 Grid Parabolic Dish 3 ft Single 28
Laird GD5W-28P Grid Parabolic Dish 3 ft Single 28
CommScope UBG600-4-1 Grid Parabolic Dish 3 ft Single 28.5
Laird GD58-29 Grid Parabolic Dish 3 ft Single 29
Laird HDGD58-29 Grid Parabolic Dish 3 ft Single 29
RadioWaves G3-5.2 Grid Parabolic Dish 3 ft Single 31.1
Wireless Beehive 5.8DP-26 Solid Parabolic 1.5 ft Dual 26
PC Tel MPRC2449 Solid Parabolic 2 ft Single 27.7
L-Com HG4958DP-30D Solid Parabolic 2 ft Dual 28
General Dynamics HQFD2-52 Solid Parabolic 2 ft Dual 28.1
PC Tel MPRD2449 Solid Parabolic 2 ft Dual 28.1
General Dynamics QFD2-52 Solid Parabolic 2 ft Dual 28.4
General Dynamics HQF2-52 Solid Parabolic 2 ft Single 28.5
General Dynamics QF2-52 Solid Parabolic 2 ft Single 28.5
L-Com HG5158DP-29D Solid Parabolic 2 ft Dual 28.5
RadioWaves HPD2-5.2 Solid Parabolic 2 ft Dual 28.6
CommScope HPX2F-52 Solid Parabolic 2 ft Dual 29
Laird HDDA5W-29-DP Solid Parabolic 2 ft Dual 29
Laird HDDA5W-29-SP Solid Parabolic 2 ft Single 29
RadioWaves SPD2-5.2 Solid Parabolic 2 ft Dual 29
RadioWaves SP2-5.2 Solid Parabolic 2 ft Single 29
Wireless Beehive 5.8DP-29 Solid Parabolic 2 ft Dual 29
CommScope P2F-57W Solid Parabolic 2 ft Single 29.3
CommScope P2F-52 Solid Parabolic 2 ft Single 29.4
CommScope PX2F-52 Solid Parabolic 2 ft Dual 29.4
ARC Wireless DA5830SD1 Solid Parabolic 2 ft Dual 30
Table 7 5GHz Antennas
Manufacturer Model Number Type Size/Diameter Polarization Gain (dBi)
