Exalt Installation and Management Guide
ExtendAir (TDD) Series Digital Microwave Radios
98 203591-011
2013-02-22
Antennas
Table 7 lists antennas supported by the ExtendAir (TDD) Series for use in the USA. In some countries,
antennas exceeding a certain level of gain may be unlawful. Refer to RF Output Power Setting
for
details on regulatory limits.
Table 7 5GHz Antennas
Manufacturer Model Number Type Size/Diameter Polarization Gain (dBi)
MTI MT-485049/NVH Panel 1 ft Dual 23
MTI MT-485025/ND Panel 1 ft Dual 23
General Dynamics EPD1-52 Panel 1 ft Single 23
Mars MA-WA58-1XMNTB Panel 1 ft Single 23
MTI MA-WA56-DP25N Panel 1 ft Dual 23.5
RadioWaves FPD1-5-24 Panel 1 ft Dual 23.8
ARC PD5823B88 Panel 1 ft Dual 24
Laird PA58-24 Panel 1 ft Single 24
Laird R2T58-24 Panel 1 ft Single 24
RadioWaves FP1-5-24 Panel 1 ft Single 24.2
Mars MA-WA56-DP25NB Panel 1 ft Dual 25
Mars MA-WA55-27B Panel 1 ft Single 26
CommScope UBP600-4-1 Panel 2 ft Single 27.5
MTI MT-466010/NVH Panel 2 ft Dual 28
General Dynamics EPD2-52 Panel 2 ft Single 28
RadioWaves FP2-5-28 Panel 2 ft Single 28
MTI MA-QA56-DP28NB Panel 2 ft Dual 28.5
MTI MT-486013/NVH Panel 2 ft Dual 29
Laird GD5W-25P Grid Parabolic Dish 2 ft Single 25
Laird GD53-25 Grid Parabolic Dish 2 ft Single 25
Laird GD57-25 Grid Parabolic Dish 2 ft Single 25
Laird HDGD58-26 Grid Parabolic Dish 2 ft Single 26
Laird GD58-26 Grid Parabolic Dish 2 ft Single 26
Commscope 28T-5801-1 Grid Parabolic Dish 3 ft Single 27
