Exalt Installation and Management Guide
ExtendAir (TDD) Series Digital Microwave Radios
203591-011 97
2013-02-22
Figure 58 Power/Ethernet connector
Pin Function
1 Paired with Pin 2
2 Paired with Pin 1
3 Paired with Pin 6
4 +DC Power (48V) In
5 +DC Power (48V) In
6 Paired with Pin 3
7 -DC Power (48V) In
8 -DC Power (48V) In
