Exalt Installation and Management Guide
ExtendAir (TDD) Series Digital Microwave Radios
203591-011 93
2013-02-22
System Specifications, 5.8GHz Band
Frequency Band 5725–5850 MHz
Tunable Range 5731–5844 MHz
Output Power (at full power) +24dBm, Mode 1 (QPSK); +20dBm 8/10MHz BW
+22dBm, Mode 2 (16 QAM)
+20dBm, Mode 3 (64 QAM)
Output Power (at minimum power) 0dBm
Selectable Channel Bandwidths 8/10MHz, 16/20MHz, 32/40MHz
Receiver Threshold (BER=10
–6
)
Maximum RSL 0dBm no damage
Mode 1: –25dBm
Mode 2 and Mode 3: –30dBm
(dBm) Mode 1 Mode 2 Mode 3
8/10MHz –86 –79 –73
16/20MHz –83 –76 –70
32/40MHz –80 –73 –67
