Exalt Installation and Management Guide
ExtendAir (TDD) Series Digital Microwave Radios
90 203591-011
2013-02-22
System Specifications, 4.9GHz Band
Frequency Band 4940–4990MHz
Tunable Range 4945–4985MHz
Output Power (at full power) +21dBm, Mode 1
+18dBm, Mode 2
+16dBm, Mode 3
Output Power (at minimum power) 0dBm
Selectable Channel Bandwidths
10MHz, 20MHz, and 40MHz
a
a. Consult your country’s regulations or Exalt Communications to determine if 40MHz is allowed for
your application.
Receiver Threshold (BER=10
–6
)
Maximum RSL 0dBm no damage
Mode 1: –25dBm error-free
Mode 2 and Mode 3: –30dBm error-free
Non-overlapping channels 10MHz: 5; 20MHz: 2; 40MHz: 1
dBm Mode 1 Mode 2 Mode 3
10MHz –86 –79 –73
20MHz –83 –76 –70
40MHz –80 –73 –67
