XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
85
The following effect types are available:
• C: Cut • W: Wipe • <: Fade from color
• M: Mix • >: Fade to color • V: Fade to/from color
4. To modify the default duration for the transition effect, press FX Dur (C ) and
move the lever until the requested duration is displayed in the last field of
the corresponding element:
111A/04 Clipname0123 00:00:29 Unk
W00:20
5. Press ENTER to validate the modifications in effect type and/or duration.
9.15 REPLACE FUNCTION
9.15.1 INTRODUCTION
The purpose of the Replace function is to automate a routine used by operators to
create effects in a playlist: the operator would loop a section or an entire playlist
back to themselves and, during the playback, add some effects externally (graphic
insertion for instance) or internally (changing the speed).
The operator would then edit the original playlist to insert the desired section into
the original playlist. That section would need to be inserted in the playlist by
matching the IN/OUT frames on the original playlist to the new clip created with
the re-recorded material.
The Replace function automates this process.
Note
The Replace function is not allowed on playlists containing growing clips.
9.15.2 ENTERING THE REPLACE FUNCTION
A secondary menu with the Replace function has been added to the Playlist Edit
mode. Pressing Menu in Playlist Edit mode brings up the following menu:
OtherAng
Replace Redo Undo
Select Replace in this secondary menu to enter the Replace function.
