A new menu appears on the LCD display of the Remote Panel, with the
corresponding message on the OSD of the output monitors, asking whether
you want to copy the original playlist to the new location or whether you
simply want to select a new, empty playlist (default choice):
Select New Playlist 13?
[Menu]: Cancel
[Enter]: Confirm
COPY NEW PLST
4. Press COPY (A key) to select the copy option. The menu becomes:
Copy Playlist 11/03
to Playlist 13 ?
[Menu]: Cancel
[Enter]: Confirm
COPY PLST+CLP NEW PLST
5. To specify whether to copy the EDL with or without the clips, do one of the
following:
• If you want to copy only the EDL without copying the elements contained
in the original playlist, press ENTER. The copy is done instantly since
there is no material to transfer.
• If you want to copy the EDL and the playlist elements themselves to your
local EVS server, press PLST + CLP (B key). The display becomes:
Copy Playlist 11 and all net. clips
to Playlist 13 ?
[Menu]: Cancel
[Enter]: Confirm
COPY PLST+CLP SHORT NEW PLST
6. To specify whether to perform a Short or Long copy, select the desired
value (SHORT or LONG) pressing the C key.
• SHORT mode (default): only the section of the elements between the
Short IN and Short OUT as defined in the playlist will be copied,
