XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
69
SPEED
The Speed function allows defining the speed at which one or all clips of playlist
will be played. Select the playback speed of the clip with the lever, then press
ENTER to validate. Values are ‘Unknown’ and from 0 to 100%.
Operators have access to the secondary lever control like when clips are replayed.
While editing the speed of a clip, pressing SHIFT + the Lever key on the Remote
allows to access the secondary lever speed defined in the menu.
FX DUR
The FX Dur function sets the duration of the transition effect. The default value
that initially appears is determined by the value set in the Setup menu. The effect
duration will affect the transition at the beginning of the selected clip. Use the
lever to adjust the value, then press ENTER to confirm.
EFFECT
The Effect function (SHIFT+C key) is used to select the type of transition effect
(Mix/Wipe/Cut/Fade). Move the lever to set the type of effect, when Effect is
highlighted. Press ENTER to validate.
For more information on the effects types, refer to the section 9.14 ‘Transition
E
ffects’, on page 81.
DELETE
The Delete function allows the operator to quickly edit a playlist by removing the
selected clip. The clip that has been «cut» can then be inserted into another
location. This clip is displayed on the second PRV output. To insert it at another
position in the playlist, simply go to that position using the jog dial and press the
Insert key (or TAKE).
