Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
66
9.8 PLAYOUT FUNCTIONS AVAILABLE FOR
PLAYLISTS
9.8.1 ROLLING A PLAYLIST
ROLLING ACTION
After recalling a playlist, you will roll the playlist using the pre-defined speed of
each clip. Use the PLAY key to start rolling the playlist.
PLAYLIST SPEED
As soon as the lever is used to start the playback or during playback, the pre-set
speed for the current clip is cancelled and set by the lever position only. The
playlist will return to pre-set speed mode as soon as another clip with a pre-set
speed is found.
Note
When using the PLAY key to start the playlist, it is recommended to set
the lever at the top position (100%). If the lever is in low position and the
operator touches it by mistake while the playlist is rolling, the playlist
could freeze on-air.
If the speed for a Super Motion clip is set to “UNK”, pressing the PLAY key on that
clip will start the playback of the playlist at 33%.
9.8.2 FUNCTIONS AVAILABLE FROM THE VGA PLAYLIST SCREEN
To use the following commands, you must be in Playlist Edit or Playlist Playout
mode:
• To enter the Playlist Edit mode, press the PLST key on the EVS Remote. The
LCD screen of the Remote displays the information about the previous, current
and next 3 clips of the playlist.
• To enter the Playlist Playout mode, press the PLST key again.
The following operations can be performed from the VGA playlist screen:
Criteria Description
Naming a
playlist
For more information, refer to the section 9.6.1 ‘How to Name a
Pl
aylist From the VGA Playlist Bank Screen’, on page 63.
Naming the
current clip
For more information, refer to the section 9.6.3 'How to Name the
Current Element in the Loaded Playlist’, on page 64.
PLAY/pause Press ALT + P to start the playback / pause of the playlist from
the current position.
