XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
65
9.7 BROWSING WITHIN A PLAYLIST
9.7.1 POSSIBLE BROWSING METHODS
You can browse within a playlist in different ways:
• Browse quickly by jumping to the first field of each clip in the playlist:
For more information, see the section 9.7.3 ‘Browsing Quickly Through a
Playlist’, on page 65.
• Browse through the content of each clip in the playlist:
For more information, see the section 9.7.2 ‘Browsing Through a Playlist’, on
pa
ge 65.
9.7.2 BROWSING THROUGH A PLAYLIST
When you load a playlist, the default playlist mode allows you to scroll up and
down through all the playlist elements.
9.7.3 BROWSING QUICKLY THROUGH A PLAYLIST
When you are neither in playlist nor in clip mode, pressing the Browse key on the
Remote Panel automatically enters the current playlist in Browse mode.
In this mode, you can quickly jump to the first field of each clip inside the playlist
by moving the jog dial. To return to the normal Playlist Edit mode, press the
Browse key again.
When you are in Playlist Edit mode, you can of course also activate the Browse
mode by pressing the Browse key.
PL11 LSM01 Paola TDUR=00:00:02:22
111A Clipname0123 00:00:29 Unk W00:10
112B Clipname4567 00:53:29 Unk W00:10
113B Clipname8910 00:33:29 Unk W00:10
Effect Edit All
Insert Speed FX Dur Delete
