Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
64
9.6.2 HOW TO NAME THE CURRENT PLAYLIST ON THE VGA
PLAYLIST SCREEN
To name the current playlist from the VGA Playlist screen, proceed as follows:
1. Press the F10 key on the keyboard to open the VGA Playlist screen.
The current playlist is displayed.
2. Type the desired name on the keyboard.
It appears in the NAME field at the bottom of the screen. Use BACKSPACE to
delete the last character, or ESC to clear the entire field.
3. Press SHIFT + F1 to assign the new name to the current playlist.
The playlist name will appear in the title bar next to the playlist number.
9.6.3 HOW TO NAME THE CURRENT ELEMENT IN THE LOADED
PLAYLIST
Note
Naming the current element of the loaded playlist will affect the original
clip.
This function is only available when the playlist is active in Playlist Edit mode
(PLST EDIT) or Playlist Playout mode (PLST DIFF) on the EVS Remote Panel.
To name the current element in the loaded playlist from the VGA Playlist screen,
proceed as follows:
1. Press the F10 key on the keyboard to open the VGA Playlist screen.
The loaded playlist is displayed and the current playlist element on the
Remote Panel is selected.
2. Type the desired name for the element on the keyboard.
It appears in the NAME field at the bottom of the screen. Use BACKSPACE to
delete the last character, or ESC to clear the entire field.
3. Press F1 to assign the new name to the current element.
The name for the current element will appear in the Name column of the
selected element.
