XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
57
9. Playlist Management
9.1 GENERAL INFORMATION
PLAYLIST CREATION
Playlists can be created on the server via the nano Remote Panel and/or the
Multicam user interface.
LIMITATION ON PLAYLIST AND TIMELINE ELEMENTS
A playlist can include up to 1000 elements.
Up to 16000 playlist elements can be saved on a server.
Up to 48000 temporary playlist elements, available for undo and redo actions, can
be stored on a server. They will be purged each time the Multicam application is
closed.
PLAYLIST LOCATION
All playlists created are automatically stored on the banks dedicated to playlists
and timelines on the server, the bank 10 of each page.
Playlists on page 10 are not available from the EVS Remote Panel (these playlists
are reserved for external protocols).
9.2 PLAYLIST MODES ON THE REMOTE
PANEL
9.2.1 INTRODUCTION
Two modes are available on the Remote Panel to access and manipulate the
playlists: the Playlist Edit mode and the Playlist Playout mode:
• The Playlist Edit mode is used to modify the playlist.
• The Playlist Playout mode is used to roll the playlist on air.
Editing the playlist in Playlist Playout mode is not possible.
