XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
49
CTL + V:PASTE (LONG COPY)
With the Long copy, the entire original clip is copied, including its guardbands, to
the destination.
1. Move the cursor to the clip/playlist location where the content of the clipboard
should be copied.
2. Press CTRL + V or click to the corresponding area on the screen.
CTL+SHIFT+V: PASTE (SHORT COPY)
With the Short copy, the material between the Short IN and Short OUT points of
the original clip, augmented by the duration of the default guardbands. This allows
saving space on the EVS server.
1. Move the cursor to the clip/playlist location where the content of the clipboard
should be copied.
2. Press CTRL + SHIFT + V.
The clip in the clipboard is copied to the selected location in Short mode.
CTL + DEL:DELETE
1. Move the cursor to the clip/playlist to delete.
2. Press CTRL + DEL or click on the corresponding area on the clip screen.
→ In CAM mode, only the camera selected is deleted
→ In CLIP mode, all cameras of the clip are deleted.
Important
A clip/playlist cannot be deleted while it is on air.
Note
• When a clip is deleted, all playlists are scanned and that clip is
removed from all of them.
• When a clip is protected, or when the “Confirm Delete Clip” is set to
“Yes” in the setup menu (p.3.1 F2), a confirmation is required to delete
the selected clip(s).
