Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
46
8.2.20 HOW TO CHANGE THE PRIMARY CAMERA OF A CLIP
1. In the Clip screen, move the cursor to the desired camera.
2. Press F4 on the keyboard or click with the stylus on the corresponding area
in the Function bar.
→ This camera becomes the new primary camera.
→ If the selected camera is a secondary camera (indicated by “=”), it
becomes the primary camera and the previous primary camera becomes the
secondary camera.
8.2.21 RECALLING A CLIP
To call a clip, proceed as follows:
1. Type either the 3 or 4 digits of the ID. Ex: 111 or 111A. The entry appears in
the Name field.
2. Press F3
o If only 3 digits are entered, the primary camera is selected
o If 4 digits are entered, the clip is selected according to the given camera
angle.
o If no clip matches the entry, no selection is done.
Note
ESC key can still be used at any time to clear the Name field.
8.2.22 HOW TO RESTRIPE THE TIMECODE OF THE CURRENT CLIP
To restripe the timecode of the current clip, proceed as follows:
1. Recall the clip by moving the cursor on the desired clip and pressing
ENTER, or by clicking on it with the stylus.
2. Press ALT + T on the keyboard to call the SET TC function.
The Set Timecode screen is displayed (without TC Type field with PAL –
refer to note below):
