XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
45
If a clip is present in a certain location, it will be highlighted in BLUE. Once
selected, it will be highlighted in ORANGE.
To cue up a clip on the primary channel controlled by the first remote, or on the
VGA Call Channel defined in the setup, simply click
1
on it with the stylus. If the
channel where the clip is supposed to be loaded is in Plst Edit mode with a PRV
channel attached, the clip will automatically cue up on the PRV channel.
8.2.18 SELECTING A CLIP WITH THE KEYBOARD
The keyboard can also be used to operate within the clip screen. The green arrows
surrounding a clip show the current cursor position. The UP, DOWN, LEFT, and
RIGHT ARROW keys on the keyboard are used to move across the screen. Only 2
banks can be viewed at a time.
To view other banks, press ALT + UP or DOWN ARROW to scroll vertically
between banks and press ALT + LEFT or RIGHT ARROW or PAGE UP,
PAGE DOWN to scroll horizontally between pages. To go to bank 1 of the current
page, press HOME and to go to the Playlist bank of the current page, press END
2
.
Once the cursor located on the desired clip, press ENTER to cue up the clip on
the primary channel controlled by the first remote, or on the VGA Call Channel
defined in the setup. If the channel where the clip is supposed to be loaded is in
Plst Edit mode with a PRV channel attached, the clip will automatically cue up on
the PRV channel.
8.2.19 HOW TO NAME A CLIP
1. In the Clip screen, select the clip to name in one of the following ways:
• Click on the clip with the stylus
• Positioning the green arrows around the desired clip with the keyboard.
2. Type in the desired name with the keyboard. All characters available from
the keyboard are accepted, including blanks.
3. Press F1:
• In CAM mode, only the camera where the cursor is located is named.
• In CLIP mode, all cameras of the clip where the cursor is located are
named.
The entry in the Name field is not cleared by pressing F1 and remains for future
use. Press BACKSPACE to delete the last character in the Name field, or press
ESC to clear the whole field.
1
“Clicking with the stylus” means pressing lightly the tip of the stylus onto the tablet.
2
Trying to access the playlist bank of page 10 will cause the Clip screen to jump to the playlist bank of page 9, since
page 10 playlists are reserved for external protocols.
