Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
44
CLIP CONTROL AREA
It is dedicated to play-out control.
Command Description
ALT + P:►/■ Plays at 100% speed except for super motion clips which
are played back at 33% speed; and pause playback on the
current picture.
ALT + R:RECUE Jumps to the Short IN point.
ALT + T: SET TC Restripes the timecode of the current clip.
ALT + Z: >ARCHIVE Allows the operator to flag a clip to place it in the archive
queue of the Xtract defined in the Setup menu (p.3.3 F1)
or in the Setup screen.
When a clip is flagged for archiving, but has not yet been
archived, its ID will be blinking green in the Clip screen. It
is permanently highlighted green when the archiving of the
clip is completed.
Depending on the mode selected with the F2 key
(CLIP/CAM), the >ARCHIVE flag is assigned only to the
camera angle of the clip selected with the green cursor
(CAM mode), or to all camera angles of the clip (CLIP
mode).
PGM X Located in the bottom right corner of the clip screen, this
field is only visible if the Call Channel VGA function has
been enabled in the Setup Menu (p. 3.1 – F5) or in the
Setup Screen, and is only effective in CAM mode, not in
CLIP mode. It allows the operator to select on which
channel clips called using the keyboard/tablet and VGA
should be loaded.
Press ALT + F1 on the keyboard to select PGM1, ALT +
F2 for PGM2/PRV, ALT + F3 for PGM3, etc. This function
is useful to load clips on channels that can not be
controlled by an EVS Remote Panel, or to allow an AP to
browse clips on a play channel not used by the main
operator. Note that if that channel is in PLST EDIT mode
with a PRV, the clip will automatically cue up on the PRV.
8.2.17 SELECTING A CLIP WITH TABLET AND STYLUS
To select a different page or bank using the stylus, click on the desired page/bank
number on the bottom line of the screen. You can also move to the adjacent
page/bank by clicking on the red arrows on the top, bottom and sides of the
screen:
• Left/right arrow: go to previous/next page.
• Up/down arrow: go to previous/next bank.
