Issue
10.04.A
XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
40
AUX CLIP
Push Aux Clip PostRoll
>Archive Cam
This function allows assigning a clip as auxiliary audio clip to the current playlist.
Press CLEAR + Aux Clip (CLEAR + SHIFT + B) to remove the current auxiliary
clip. Refer to the Chapter 9 ‘Playlist Management’, on page 57 for more details.
POSTROLL
Push Aux Clip PostRoll
>Archive Cam
This function enables/disables the Post-Roll mode. This mode is explained in
details in the section ‘PostRoll’, on page 40.
CLIP/CAM
Push Aux Clip PostRoll
>Archive Cam
Pressing the D key will toggle between CAM and CLIP modes on the remote.
Please note that this mode on the remote and on the VGA screens is never
synchronized. In CAM mode, the Archive assignment will apply only to the camera
angles of the clip loaded on the controlled channels. In CLIP mode, this function
will apply on all camera angles of the clip.
8.2.10 USING THE CLIP SCREEN
8.2.11 L
ICENSE CODE
Note
The clip screen access is a software option, which requires the license
code 88 being installed. For more information on the required license key,
contact the Support or Sales team.
The VGA Clip screen is accessed by selecting the F9 key on the keyboard. With
this screen, clips can be recalled using the pen and tablet or directly from the
keyboard.
Important
The action performed on a channel from the Clip screen is concurrent to
any other controller that might be assigned to that channel by EVS
Remote Panel. A command sent from the Clip screen to a channel will
overwrite whatever the channel was doing at that time.
