In the secondary menu, clips can still be directly recalled using the F1-F10 keys of
the Remote Panel.
The ID of the current clip appears on the end of line 3 of the LCD display.
PUSH
Push Aux Clip PostRoll
>Archive Cam
Introduction
The Push function allows you to easily send a copy of a clip to another machine
on the network.
Principle
•
If one or two default targets (push machines) are defined in the setup, the clip
will be automatically sent to these machines.
• If no default target is defined, the list of machines available on the network will
appear. As soon as the operator selects one of them, the clip is pushed.
For more information about the Push settings, refer to the Remote Panel
setup, page 3.3.
In both cases, a message appears for a few seconds on the LCD to confirm that
the clip is being pushed and indicating the clip location where it will be stored on
the receiving machine.
If the Receive Page(s) defined on the destination machine is (are) full, the
operator who tries pushing the clip is notified. While this message is being
displayed, the operator can press the MENU key at any time to return to the
normal menu. Depending on the CAM/CLIP mode selected by the D key, only the
camera angles loaded on the controlled channels are pushed (CAM mode), or all
camera angles of the clip are pushed at once (CLIP mode).
>ARCHIVE
Push Aux Clip PostRoll
>Archive Cam
The Archive function allows the operator to flag a clip to place it in the archive
queue of the Xtract.
This function is blinking when the clip is flagged for archiving, but has not yet
been archived. It is permanently highlighted when the archiving of the clip is
completed.
Depending on the mode selected with the D key (CLIP/CAM), the >ARCHIVE flag
is assigned only to the camera angles of the clip loaded on the controlled
channels (CAM mode), or to all camera angles of the clip (CLIP mode).
