XTnano
–
Version 10.04
–
Operating Manual
EVS Broadcast Equipment SA – January 2011
Issue
10.04.A
27
7. Multi PGM Mode
7.1 1/2 PGM MODES (PRESS A OR B FROM
MAIN MENU)
Multicam has two modes for its basic operation, 1 PRV/PGM mode or Multi PGM
mode:
• The 1PGM + PRV mode, as described previously, is the more powerful of the
two, allowing for interaction between all outputs. Here, synchronized replays
can be rolled and chained between the cameras with either a mix, wipe, or cut
between them.
• The MULTI PGM mode is more basic, which gives the operator independent
control of all outputs.
In this mode, all outputs can be controlled together (such as jogging back to a
certain action, with all outputs) or they can be controlled individually (either PGM
1 or 2).
PGM 1 CAM A *PGM2* CAM B PGM3 CAM C
Aud Met. PgmSpd PostRoll
Mix. Sw To In Pref
P.1 B.1 Clips: LOCAL Records: LOCAL
PL 11: <
Msg:
Rst Cam Sync To
PGM 1 PGM 2
7.1.1 SECONDARY MENU
The secondary menu can be called by pressing the MENU key and is identical to
the 1Pgm+Prv mode.
7.1.2 OPERATIONAL MENU
The operational menu in Multi PGM mode gives access to the functions detailed in
the following paragraphs:
Rst Cam Sync To
PGM 1 PGM 2
