PGMSPD/VARMAX
Aud.Met. PgmSpd PostRoll
Mix. Sw To In Pref
Pressing PgmSpd once enables the Program Speed mode and highlights this
function on the LCD. Pressing the key once more enables the VarMax mode and
highlights this function on the LCD. The PLAY key is flashing red while either of
these modes is enabled.
• Program Speed mode: In this mode, only two speed values are available from
the lever: 0% when the lever is in the lower position, or the speed defined in
the setup (p.6.1 F3) for any other position of the lever.
• Var Max mode: the speed range defined by the lever is limited between 0% and
the speed value defined in the setup (p.6.1 F3).
SW TO IN
Aud.Met. PgmSpd PostRoll
Mix. Sw To In Pref
When this function is enabled (highlighted), a camera change will cause a jump to
the corresponding IN point if existing. It will switch in Sync if no IN point exists for
the current element, or if Sw To In is OFF.
PREF
Aud.Met. PgmSpd PostRoll
Mix. Sw To In Pref
Selecting this function enables the Preference mode.
AUD.MET.
Aud.Met. PgmSpd PostRoll
Mix. Sw To In Pref
This option enables/disables the display of audio meters for all channels using the
OSD of the output monitors.
POSTROLL
Aud.Met. PgmSpd PostRoll
Mix. Sw To In Pref
When the Post-Roll mode is enabled, that function is highlighted on the LCD and a
“P” appears on the OSD of the output monitors.
When the user exits Multicam with the Post-Roll mode on, this mode will still be
enabled when Multicam is restarted.
The Post-Roll mode works as follows depending on the element played:
